Basic Technical Information
Operating Temperature
Cryogenic to 500° F
Pressure Range
150# gaskets to 285 MAWP (1)
300# gaskets to 740 MAWP (1)
Gasket Seating Stress
18,000-psi (150#) and 20,750 (300#) (2) (3) (4)
Size Availability
ASME Flanges - 1/2" to 24" - Classes 150, 300 and 600
Materials of Construction
KAG Core, HF Acid
Monel 400, Standard
Carbon Steel, Optional
KAG Core, Sulfuric Acid
316 Stainless Steel, Standard
KAG Facing Material
APX2 Low-Oxidation Flexible Graphite (GR600 Grade)
Barrier Pillow
1/4” E-PTFE, Standard
Centering Ring
Carbon Steel, Color Coded per ASME B16.20
Notes
(1) KAG seal will hold to 3,000-psi when properly installed
(2) Averages for series. Gasket stress chart available upon request
(3) When installed per instructions
(4) Torque values and instructions provided with gaskets
